Parameter:
| Model | AZ-IP861F-2MP | AZ-IP861F-3MP |
|---|---|---|
| Image Sensor | XM510+F37 | HI3516EV200+SC4239 |
| TV System | PAL/NTSC | |
| Image Resolution | 1920*1080P | 2048*1536 |
| Horizontal Resolution | 2.0MP | 3.0MP |
| SYNC. | Internal | |
| Video Out | 1.0Vp-p Composite Signal (75ohm) | |
| Minimum illuminator | 0 .001Lux (Infrared Light Open) | |
| Gama adjust | 0.45 | |
| Infrared Sensitivity | Support | |
| S/N Ratio | 58dB(min)(AGC closed) | |
| Lens | 3.6mm HD 3MP Lens | |
| Leds | 24 pcs IR Led | |
| IR Distance | 35 m | |
| DNR | Yes | |
| AWB | AUTO | |
| AGC | AUTO | |
| BLC | ON/OFF | |
| Day/Night | Yes | |
| OSD | / | |
| Compression Technology | H.265 Main Profile @level 3 | |
| Max Coding Rate | 128-8192kbps | |
| Encoding Type | CBR or VBR | |
| R/N Ratio | More than 50DB | |
| Image intensification | Brightness, Contrast, Saturation, HU Adjustable | |
| Subtitle Input | Support Channels name, Date & time | |
| Video Orientation | Left & Right Mirror, Up & down Flip | |
| Audio input | Optional | |
| Audio Format | G.711/G.726 | |
| Alarm | Motion Detection(Sensitivity adjustable) | |
| Alert Processing | Control Center monitoring, go to preset point, Email send MSG, Log Record, Video & PIC save on PC | |
| Network Port | Ethernet(10M/100M Base-T),RJ45 | |
| Safety | IP Address Filtering, User rank protect, User login log | |
| Software management | CMS, Onvif support different platform software | |
| Video Protocol | TCP,UDP,IP,HTTP,FTP,SMTP,DHCP,DNS,ARP,ICMP,POP3,NTP,RTP, and RTSP, Onvif2.0 | |
| Network Port | Support DDNS, P2P(NAT),software remote access | |
| Power Input | DC12V±1V | |
| Operation Temperature | Temperature -10℃～+75℃,Humidity less than 85%RH | |
| OSD Language | Chinese English | |
| Dimension | 93(H)*121(D) mm | |
| Weight | 0.30KG | |
| Video Output | 1.0Vp-p,75Ω | |
We are sincere hope ro estabish long-term business relationship with you in the near future. If you are interested in our or have any further questions,please do not hesitate to contact us. We can ensure to provide the products with high quality and reasonable price to you. Welcome your trial orders.
