Parameter:
| Model | AZ-IP861F-2MP | ST-IP861F-3MP |
|---|---|---|
| Image Sensor | XM510+F37 | HI3516EV200+SC4239 |
| TV System | PAL/NTSC | |
| Image Resolution | 1920*1080P | 2048*1536 |
| Horizontal Resolution | 2.0MP | 3.0MP |
| SYNC. | Internal | |
| Video Out | 1.0Vp-p Composite Signal (75ohm) | |
| Minimum illuminator | 0 .001Lux (Infrared Light Open) | |
| Gama adjust | 0.45 | |
| Infrared Sensitivity | Support | |
| S/N Ratio | 58dB(min)(AGC closed) | |
| Lens | 3.6mm HD 3MP Lens | |
| Leds | 14µ New High Brightness LEDs x 12PCS | |
| IR Distance | 35 m | |
| DNR | Yes | |
| AWB | AUTO | |
| AGC | AUTO | |
| BLC | ON/OFF | |
| Day/Night | Yes | |
| OSD | / | |
| Compression Technology | H.265 Main Profile @level 3 | |
| Max Coding Rate | 128-8192kbps | |
| Encoding Type | CBR or VBR | |
| R/N Ratio | More than 50DB | |
| Image intensification | Brightness, Contrast, Saturation, HU Adjustable | |
| Subtitle Input | Support Channels name, Date & time | |
| Video Orientation | Left & Right Mirror, Up & down Flip | |
| Audio input | Optional | |
| Audio Format | G.711/G.726 | |
| Alarm | Motion Detection(Sensitivity adjustable) | |
| Alert Processing | Control Center monitoring, go to preset point, Email send MSG, Log Record, Video & PIC save on PC | |
| Network Port | Ethernet(10M/100M Base-T),RJ45 | |
| Safety | IP Address Filtering, User rank protect, User login log | |
| Software management | CMS, Onvif support different platform software | |
| Video Protocol | TCP,UDP,IP,HTTP,FTP,SMTP,DHCP,DNS,ARP,ICMP,POP3,NTP,RTP, and RTSP, Onvif2.0 | |
| Network Port | Support DDNS, P2P(NAT),software remote access | |
| Power Input | DC12V±1V | |
| Operation Temperature | Temperature -10℃～+75℃,Humidity less than 85%RH | |
| OSD Language | Chinese English | |
| Dimension | 93(H)*121(D) mm | |
| Weight | 0.30KG | |
| Video Output | 1.0Vp-p,75Ω | |
