| Specification parameter | |||
|---|---|---|---|
| system | Main Processor | Dual-core 32-bit DSP (XM650V200), pure hard compression, watchdog | |
| image sensor | 2 2m 1/2.8" SC233A High performance CMOS sensors | ||
| Operation System | Embedded LINUX operating system | ||
| Video Compression | Smart H.265X | ||
| APP | Super Look (Android and IOS support) | ||
| Video | High Definition | 2*2MP | |
| Image resolution | Main code stream: 1920*2160@12fps; Substream: 800*896@12fps | ||
| Minimum illumination | 0.01 LUX/pro series | ||
| Lens | 3.6mm(standard) | ||
| Perspective | 92 ° | ||
| Turn video | Flip up and down/flip side to side | ||
| lighting | Light control mode | Starlight full color/intelligent warning/infrared night vision | |
| Number of lights | 8 red lights +4 white lights | ||
| PTZ | PTZ control | Rotation Angle level :355°; Vertical :90° | |
| Turn PTZ | Flip up and down/flip side to side | ||
| Audio | Coding standard | G.711 | |
| Mitou | support | ||
| Two-way Speech | support | ||
| Record management | Video file size | ≈6G/ day | |
| Record Mode | Manual video recording, dynamic detection video recording, timing video recording, alarm video | ||
| Video storage | TF card/cloud | ||
| storage | Cloud Storage +TF Local Video recording (128GB Max) | ||
| Remote playback | support | ||
| Image capture | support | ||
| Network | WIFI | 2.4G WIFI 802.11b/g/n | |
| Pairing | WiFi Smartlink distribution network addition, AP hotspot addition, QR code scanning | ||
| Network Protocol | TCP/IP, ONVIF, RTSP | ||
| extension | Reset key | support | |
| Human tracking | support | ||
| 360degree coordinate positioning | support | ||
| power supply | Power | DC 5V 1.6A | |
| power interfac | Micro Type-A | ||
| work environment | Suitable place | outdoor、Home、shop、School、factory； | |
| Installation mode | Wall hanging, lifting, flat | ||
| Working Temperature | -20℃－＋55℃ | ||
| Working humidity | 10%－90% | ||
